BOILER REPLACEMENT STATION
BA-HTA

It replaces conventional gas boilers and efficiently uses the existing heating energy to produce hot water. The station can be flexibly connected to various heat sources – buffer storage tanks, district heating, combined heat and power plants, or central heating systems.

Characteristics

Thermostatic temperature controller: Constant warm drinking water preparation without electrical energy.
Flexible variant: Available with drinking water inlet either at the top or bottom, depending on the structural conditions.
Unregulated heating connection: Offers simple and flexible connection options.
Differential pressure regulator: Stabilizes differential pressure in primary circuit and ensures constant flow control.
Protection and comfort: Includes water hammer damper for a secure water supply.
Surface mounting with cover: White covering in RAL 9016.
Stainless steel piping: Robust, corrosion-resistant pipes (18x1 mm).

Domestic hot water preparation
The drinking water is heated using the flow principle through a stainless steel plate heat exchanger only when it is needed. The thermostatic temperature controller ensures that the hot water temperature remains constant regardless of the amount of tapped water, the heating water temperature or usage intervals. An integrated differential pressure regulator stabilizes the pressure in the heating system and ensures a constant flow rate. The station can be connected to heating systems with buffer storage tanks as well as directly to a secondary district heating network or a combined heat and power plant. A universal installation section for cold water and heat meters is integrated into the hard foam insulation box. The underfloor heating is controlled by a thermostatic temperature regulator, which ensures a constant and comfortable temperature.
We recommend the additional installation of thermostatic mixing valves to avoid temperature fluctuations in the hot water outlet.

ORDER NO.
2250011	Cold water connection at the bottom, surface-mounted, copper plate heat exchanger, hot water capacity M
2250013	Cold water connection at the bottom, surface-mounted, copper plate heat exchanger, hot water capacity XL
2250111	Cold water connection at the bottom, surface-mounted, stainless steel plate heat exchanger, hot water capacity M
2250113	Cold water connection at the bottom, surface-mounted, stainless steel plate heat exchanger, hot water capacity XL
2250012	Cold water connection at top, surface-mounted, copper plate heat exchanger, hot water capacity M
2250014	Cold water connection at top, surface-mounted, copper plate heat exchanger, hot water capacity XL
2250112	Cold water connection at top, surface-mounted, stainless steel plate heat exchanger, hot water capacity M
2250114	Cold water connection at top, surface-mounted, stainless steel plate heat exchanger, hot water capacity XL
